Açıklama
Elektrik Verisi
Ratings per IEC/EN
1'e göre derecelendirme
IEC/EN 60947-7-1
Overvoltage category
III
III
II
Pollution degree
3
2
2
Anma gerilimi
500 V
-
-
Şok gerilimi
6 kV
-
-
Nominal akım
13.5 A
-
-
Approvals per UL 1059
Approvals per
UL 1059
Use group
B
C
D
Rated voltage
300 V
300 V
-
Rated current
10 A
10 A
-
Approvals per CSA
Approvals per
CSA 22.2 No 158
Use group
B
C
D
Rated voltage
300 V
300 V
-
Rated current
10 A
10 A
-
Ex information
| Reference hazardous areas | See “Downloads – Documentation – Additional Information: Technical Section; Technical Explications” |
| Ratings per | ATEX: PTB 19 ATEX 1019 U / IECEx: PTB 19.0050U (Ex eb IIC Gb) |
| Anma gerilimi EN (Ex e II) | 352 V |
| Nominal akım (Ex e II) | 13,5 A |
| Nominal akım (Ex e II) | 12 A |
Power loss
| Rated current I N for specified power loss | 13,5 A |
| Resistance value for specified, current-dependent power loss | 0,002 Ω |
Bağlantı verisi
| Toplam bağlantı noktası |
