Açıklama
Technical Data
Control circuit
| Nominal input voltage U N | DC 24 V |
| Input voltage range | -30 … +25 % |
| Nominal input current at U N | 40 mA |
Load circuit
| Number of changeover/switchover contacts | 2 |
| Contact material (relay) | AgNi 0.15 |
| Limiting continuous current | 5 A |
| Max. switching voltage | AC 250 V |
| Max. switching power (resistive) | AC 1750 VA |
| Çekme süresi (tip.) | 18 ms |
| Bırakma süresi | 3 ms |
| Sıçrama süresi (tip.) | 2 ms |
Signaling
| Durum göstergesi | Kırmızı LED |
Safety and protection
| Anma gerilimi | 250 V |
| Nominal ani dalgalanma gerilimi | 4 kV |
| Kirlilik derecesi | 2 |
| Dielectric strength, control/load circuit (AC, 1 min) | 2 kVrms |
| Dielectric strength open contact (AC, 1 min) | 1 kVrms |
| Dielectric strength, load/load circuit (AC, 1 min) | 1,5 kVrms |
| Koruma sınıfı | IP20 |
Geometrical Data
| Width | 20 mm / 0.787 inches |
| Height | 82,5 mm / 3.248 inches |
| Depth | 52 mm / 2.047 inches |
Mechanical data
| Montaj | Priz klemensleri için tak-çıkar modül |
Material Data
| Renk | gri |
| Yangın yükü | 0,512 MJ |
| Ağırlık | 39,8 g |
Environmental Requirements
| Surrounding air (operating) temperature at U N | -25 … +70 °C |
| Surrounding air (storage) temperature | -25 … +70 °C |
| İşlem sıcaklığı | -25 … +50 °C |
| Relative humidity | 5 … 85 % (yoğunlaşmaya izin verilmez) |
| Max. operating altitude | 2000 m |
Standartlar ve Spesifikasyonlar
| Standartlar/spesifikasyonlar | EN 60664-1 |
Ticari Veri
| Product Group | 6 (INTERFACE ELECTRONIC) |
| eCl@ss 10.0 | 27-37-16-01 |
| eCl@ss 10.0 | 27-37-16-01 |
| ETIM 8.0 | EC001437 |
| ETIM 8.0 | EC001437 |
| Recupel Type | |
| Pack. unit | 10 (1) Adet |
| SAP'den ambalaj tipi | box |
| SAP tesis 01'den menşei | DE |
| GTIN | 4055143105002 |
| SAP tesis 01'den gümrük tarifesi no. | 85364900990 |
Environmental Product Compliance
| CAS-No. | 7439-92-1 79-94-7 80-05-7 |
| REACH Candidate List Substance | 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol 4,4'-isopropylidenediphenol Lead |
| RoHS Compliance Status | Compliant,With Exemption |
| RoHS Exemption | 7(a) 7(c)-I 7(c)-II |
| SCIP notification number (Austria) | 9c84a57e-6690-4ae0-9b63-573818a80080 |
| SCIP notification number (Belgium) | a7eef949-7200-4d35-b29b-5d0e86ceca81 |
| SCIP notification number (Bulgaria) | c1b1adff-2ba4-442e-91fe-e02eef35c46d |
| SCIP notification number (Czech Republic) | ebf71a7e-a340-4b97-8abc-7bb4b2d39739 |
| SCIP notification number (Denmark) | 9f55582a-ef02-4cf9-96e0-584092645892 |
| SCIP notification number (Finland) | cc55ab8c-d42d-4e6c-8e64-08e510c11311 |
| SCIP notification number (France) | 6582b6ef-a2d6-4492-b1fa-40f844f1d063 |
| SCIP notification number (Germany) | d8071b10-b64f-45c7-867a-c339837127d7 |
| SCIP notification number (Hungary) | 731c5638-6be0-4cb6-8914-944ef8a7213f |
| SCIP notification number (Italy) | fd20a48b-c587-4c30-83ff-2b899f3644d9 |
| SCIP notification number (Netherlands) | 20e1bf2f-b5f9-48da-8f09-661a466e2a7c |
| SCIP notification number (Poland) | 8c887e13-7e60-40aa-88c2-cd70326ad14b |
| SCIP notification number (Romania) | 9627ad70-e850-4f6b-9e58-2f8921c9b7c9 |
| SCIP notification number (Sweden) | 218f7f48-2845-41d9-a59f-a9bd5b96e945 |
