Açıklama
Technical Data
Control circuit
| Nominal input voltage U N | DC 24 V |
| Input voltage range | ±10 % |
| Nominal input current at U N | 21 mA |
Load circuit
| Number of break contacts/switch off contacts | 1 |
| Contact material (relay) | AgNi |
| Limiting continuous current | 5 A |
| Max. switching voltage | AC 250 V |
| Max. switching power (resistive) | AC 1250 VA |
| Çekme süresi (tip.) | 10 ms |
| Bırakma süresi | 4 ms |
| Sıçrama süresi (tip.) | 3 ms |
| Mekanik ömür | 5 x 10⁶ switching operations |
Signaling
| Durum göstergesi | Kırmızı LED |
Safety and protection
| Anma gerilimi | 250 V |
| Nominal ani dalgalanma gerilimi | 4 kV |
| Kirlilik derecesi | 2 |
| Dielectric strength, control/load circuit (AC, 1 min) | 4 kVrms |
| Koruma sınıfı | IP20 |
Geometrical Data
| Width | 10 mm / 0.394 inches |
| Height | 82,5 mm / 3.248 inches |
| Depth | 52 mm / 2.047 inches |
Mechanical data
| Montaj | Priz klemensleri için tak-çıkar modül |
Material Data
| Renk | gri |
| Yangın yükü | 0,298 MJ |
| Ağırlık | 19,1 g |
Environmental Requirements
| Surrounding air (operating) temperature at U N | -25 … +40 °C |
| Surrounding air (storage) temperature | -25 … +70 °C |
| İşlem sıcaklığı | -25 … +50 °C |
| Relative humidity | 5 … 85 % (yoğunlaşmaya izin verilmez) |
| Max. operating altitude | 2000 m |
Standartlar ve Spesifikasyonlar
| Standartlar/spesifikasyonlar | EN 60664-1 |
Ticari Veri
| Product Group | 6 (INTERFACE ELECTRONIC) |
| eCl@ss 10.0 | 27-37-16-01 |
| eCl@ss 10.0 | 27-37-16-01 |
| ETIM 8.0 | EC001437 |
| ETIM 8.0 | EC001437 |
| Recupel Type | |
| Pack. unit | 25 (1) Adet |
| SAP'den ambalaj tipi | box |
| SAP tesis 01'den menşei | DE |
| GTIN | 4045454384036 |
| SAP tesis 01'den gümrük tarifesi no. | 85364900990 |
Environmental Product Compliance
| CAS-No. | 7439-92-1 79-94-7 |
| REACH Candidate List Substance | 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol Lead |
| RoHS Compliance Status | Compliant,With Exemption |
| RoHS Exemption | 7(a) 7(c)-I 7(c)-II |
| SCIP notification number (Austria) | 36497ae2-55f1-4340-a81f-1e3485ef3972 |
| SCIP notification number (Belgium) | b642b671-8ef5-4906-a7c9-2f5e80fe3660 |
| SCIP notification number (Bulgaria) | c91ef76f-81f8-4e0e-9eec-3ad9927ebe53 |
| SCIP notification number (Czech Republic) | 60779511-3574-4177-a2cf-6420095228d6 |
| SCIP notification number (Denmark) | 35baaaa6-709f-4bed-b488-23c9643ba34c |
| SCIP notification number (Finland) | 6d55146d-e74d-43c3-b45a-f2ff48aee3dd |
| SCIP notification number (France) | 32d9add0-26d8-401c-a183-e3085d344995 |
| SCIP notification number (Germany) | a778b3e8-9df1-4ab0-91fb-a1ba9f4ae9a0 |
| SCIP notification number (Hungary) | f5ec93a7-19f8-40b6-85d7-6461ddd04598 |
| SCIP notification number (Italy) | 66b4be46-be73-4cfd-a2a9-98c21d72800c |
| SCIP notification number (Netherlands) | 4af6202b-3d13-4512-9868-8ebe884382b1 |
| SCIP notification number (Poland) | 578745b3-9a9c-4d14-8e14-31ed5af9dd23 |
| SCIP notification number (Romania) | dbbe6f5e-f2e5-4ca1-a316-1c294a64b9fc |
| SCIP notification number (Sweden) | 924ac231-e702-4595-bed8-287a6eb8202a |
