Açıklama
Technical Data
Input
| Phases | 1 |
| Nominal input voltage U i nom | 1 x AC 230 V |
| Input voltage range | ±10 % |
| Nominal mains frequency range | 50 … 60 Hz |
Output
| Nominal output voltage U o nom | DC 15 / -15 V |
| Output voltage range | ±4 % |
| Nominal output current I o nom | 2 x 0,5 A |
| Residual ripple | ≤ 10 mV (tepe-tepe) |
Verim/Güç Kayıpları
| Max. power loss P v max. | 27 W |
Sigorta Koruması
| Dahili sigorta | 2 x T0,8A |
Safety and protection
| Koruma sınıfı | III |
| Koruma sınıfı | IP00; per EN 60529 |
| Kirlilik derecesi | 2 |
| Series connection | hayır |
Bağlantı verisi
| Bağlantı teknolojisi | CAGE CLAMP® |
| WAGO terminal | WAGO 236 Serisi |
| Tek damarlı boylar | 0,08 … 2,5 mm² / 28 … 12 AWG |
| İnce bükümlü kablolar | 0,08 … 2,5 mm² / 28 … 12 AWG |
| Sıyırma uzunluğu | 5 … 6 mm / 0.2 … 0.24 inches |
| Not (iletken kesiti) | 12 AWG: THHN, THWN |
Geometrical Data
| Width | 94 mm / 3.701 inches |
| Height | 106 mm / 4.173 inches |
| Depth | 57 mm / 2.244 inches |
Mekanik Veri
| Tasarım | Montaj taşıyıcısı |
| Montaj | DIN-35 ray DIN 35 ray |
Material Data
| Yangın yükü | 1,397 MJ |
| Ağırlık | 681,8 g |
Environmental Requirements
| Surrounding air (operating) temperature | 0 … +40 °C |
Standartlar ve Spesifikasyonlar
| Uygunluk işareti | CE |
Ticari Veri
| Product Group | 6 (INTERFACE ELECTRONIC) |
| eCl@ss 10.0 | 27-04-07-01 |
| eCl@ss 10.0 | 27-04-07-01 |
| ETIM 8.0 | EC002540 |
| ETIM 8.0 | EC002540 |
| Recupel Type | |
| Pack. unit | 1 Adet |
| SAP'den ambalaj tipi | box |
| SAP tesis 01'den menşei | DE |
| GTIN | 4050821155515 |
| SAP tesis 01'den gümrük tarifesi no. | 85044083900 |
Environmental Product Compliance
| CAS-No. | 7439-92-1 79-94-7 |
| REACH Candidate List Substance | 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol Lead |
| RoHS Compliance Status | Compliant,With Exemption |
| RoHS Exemption | 6(c) 7(a) 7(c)-I 7(c)-II |
| SCIP notification number (Austria) | 318d28b4-169d-4049-8c49-476eddad18b8 |
| SCIP notification number (Belgium) | 613a637d-4cf1-44f4-8aee-1f20e883f629 |
| SCIP notification number (Bulgaria) | a52b8aa0-1e85-4b7b-9408-ae8bf205c29a |
| SCIP notification number (Czech Republic) | 188232d1-ecbb-4dab-b6c5-79a03e4c0ac1 |
| SCIP notification number (Denmark) | 7eddfda7-823f-47b1-9428-8fd062091992 |
| SCIP notification number (Finland) | 8ce47e0d-653c-44cc-acaf-383ddb7b871b |
| SCIP notification number (France) | 376a5b24-1909-4c4c-9a6d-eb10d31eba1f |
| SCIP notification number (Germany) | 4bde2143-59f5-4405-b2d5-7f34018fa910 |
| SCIP notification number (Hungary) | 32cc4aa5-ea72-4a2b-a088-b314e0af0fec |
| SCIP notification number (Italy) | 6728f342-a3ef-4823-81a5-78826fd022e7 |
| SCIP notification number (Netherlands) | 6f6c0920-8845-41ba-8cbf-7d755aa9a645 |
| SCIP notification number (Poland) | f593958d-bc0f-4899-a114-ddbbc7836865 |
| SCIP notification number (Romania) | 4a822f3e-e573-42a6-bc38-59de3d7e2a31 |
| SCIP notification number (Sweden) | 64c53bfe-6174-4ed9-8e80-34ab7f8367dd |
