Açıklama
Technical Data
Input
| Input voltage range | DC 27 … 35 V |
| Nominal mains frequency range | 0 Hz |
Output
| Nominal output voltage U o nom | DC 24 V |
| Output voltage range | ±10 % |
| Nominal output current I o nom | 3 A |
Safety and protection
| Koruma sınıfı | IP00; per EN 60529 |
| Kirlilik derecesi | 2 |
| Series connection | hayır |
Bağlantı verisi
| Bağlantı teknolojisi | CAGE CLAMP® |
| WAGO terminal | WAGO 236 Serisi |
| Tek damarlı boylar | 0,08 … 2,5 mm² / 28 … 12 AWG |
| İnce bükümlü kablolar | 0,08 … 2,5 mm² / 28 … 12 AWG |
| Sıyırma uzunluğu | 5 … 6 mm / 0.2 … 0.24 inches |
| Not (iletken kesiti) | 12 AWG: THHN, THWN |
Geometrical Data
| Width | 78,5 mm / 3.091 inches |
| Height | 39 mm / 1.535 inches |
| Depth | 66 mm / 2.598 inches |
Mekanik Veri
| Tasarım | Montaj ayaklı PCB |
| Montaj | DIN-35 ray DIN 35 ray |
Material Data
| Yangın yükü | 0,054 MJ |
| Ağırlık | 170,7 g |
Environmental Requirements
| Surrounding air (operating) temperature | -25 … +40 °C |
Standartlar ve Spesifikasyonlar
| Uygunluk işareti | CE |
Ticari Veri
| Product Group | 6 (INTERFACE ELECTRONIC) |
| eCl@ss 10.0 | 27-04-07-01 |
| eCl@ss 10.0 | 27-04-07-01 |
| ETIM 8.0 | EC002540 |
| ETIM 8.0 | EC002540 |
| Pack. unit | 10 (1) Adet |
| SAP'den ambalaj tipi | box |
| SAP tesis 01'den menşei | DE |
| GTIN | 4050821157557 |
| SAP tesis 01'den gümrük tarifesi no. | 85044083900 |
Environmental Product Compliance
| CAS-No. | 1303-86-2 1317-36-8 7439-92-1 79-94-7 |
| REACH Candidate List Substance | 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol Diboron trioxide Lead Lead monoxide |
| RoHS Compliance Status | Compliant,With Exemption |
| RoHS Exemption | 6(c) 7(a) 7(c)-I 7(c)-II |
