Açıklama
Technical Data
Control circuit
| Nominal input voltage U N | DC 24 V |
Load circuit
| Number of changeover/switchover contacts | 1 |
| Contact material (relay) | AgNi |
| Limiting continuous current | 16 A |
| Max. make current (resistive) | (AC) 24 A |
| Max. switching voltage | AC 250 V |
| Max. switching power (resistive) | AC 4000 VA; DC (yük limit eğrisine bakın) |
| Switching capacity | AC-15: 3 A / AC 240 V; DC-13: 2 A / DC 24 V |
| Recommended minimum load | 12 V / 10 mA |
| Çekme süresi (tip.) | 15 ms |
| Bırakma süresi | 8 ms |
| Sıçrama süresi (tip.) | 6 ms |
| Electrical life (N.O.; resistive load; 23 °C) | 10 x 10³ switching operations |
| Mekanik ömür | 5 x 10⁶ switching operations |
| Max. switching load with load/without load | 6 min -1 / 300 min -1 |
Signaling
| Durum göstergesi | Mekanik |
Safety and protection
| Dielectric strength, control/load circuit (AC, 1 min) | 5 kVrms |
| Dielectric strength open contact (AC, 1 min) | 1 kVrms |
| Koruma sınıfı | IP20 |
Geometrical Data
| Width | 12,7 mm / 0.5 inches |
| Depth | 29 mm / 1.142 inches |
Mechanical data
| Montaj | Tak-çıkar modül |
Material Data
| Ağırlık | 15,2 g |
Environmental Requirements
| Surrounding air (operating) temperature at U N | -40 … +70 °C |
| Surrounding air (storage) temperature | -40 … +85 °C |
Standartlar ve Spesifikasyonlar
| Standartlar/spesifikasyonlar |
Ticari Veri
| ETIM 8.0 | EC001437 |
| ETIM 8.0 | EC001437 |
| Pack. unit | 8 Adet |
| SAP'den ambalaj tipi | box |
| SAP tesis 01'den menşei | |
| GTIN | |
| SAP tesis 01'den gümrük tarifesi no. |
Environmental Product Compliance
| RoHS Compliance Status | Compliant,No Exemption |
