Açıklama
Technical Data
| Switchingmodus | Mağaza ve ileri; engellemeyen Store-and-Forward, non-blocking |
| Number of 1000Base-T ports | 8 |
| Number of 1000Base SX/LX ports | 2 |
| Communication standards | IEEE 802.3x Akış Kontrolü IEEE 802.1d Kapsayan Ağaç Protokolü (STP) IEEE 802.1w Hızlı Genişleme Ağacı Protokolü (RSTP) IEEE 802.1Q VLAN Etiketleme Önceliklendirilen IEEE 802.1p IEEE 802.1x Bağlantı Noktası Kimlik Doğrulaması IEEE 802.1ab Bağlantı Katmanı Bulma Protokolü (LLDP) IEEE 802.3af Ethernet üzerinden Güç (PoE+) IEEE 802.3af Ethernet üzerinden Yüksek Güç (PoE+) IEEE 802.3az Enerji Tasarruflu Ethernet ITU-T G8032v1 / v2 Ethernet Halka Koruma Anahtarlaması (ERPS) IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX/FX IEEE 802.3ab 1000BASE-T IEEE 802.3x Flow Control IEEE 802.1d Spanning Tree Protocol (STP) IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) IEEE 802.1Q VLAN Tagging IEEE 802.1p Prioritization IEEE 802.1x Port Authentication IEEE 802.1ab Link Layer Discovery Protocol (LLDP) IEEE 802.3af Power over Ethernet (PoE) IEEE 802.3at High Power over Ethernet (PoE+) IEEE 802.3az Energy Efficient Ethernet ITU-T G8032v1/v2 Ethernet Ring Protection Switching (ERPS) |
| Yedeklilik fonksiyonu | Redundant DC power supply; STP; RSTP; ERPSv1/v2 (max. 2 rings per switch, max. 16 switches per ring, switching time < 800 ms) Redundant DC power supply; STP; RSTP; ERPSv1/v2 (max. 2 rings per switch, max. 16 switches per ring, switching time < 800 ms) |
| Configuration options | Sinyal kontağı için DIP anahtarı Web Tabanlı Yönetim Komut satırı arayüzü SNMPv1/v2c/v3 |
| Arıza teşhisi | Signal contact; Modbus TCP; port status; port statistics; port load; traffic monitor; syslog; SNMP traps; loop detection; diagnostics dashboard; topology map |
| Safety | Access-control list with max. 32 entries; port security; IEEE 802.1X authentication Access Control List mit max. 32 Einträgen; Port Security; Authentication IEEE 802.1X |
| MAC tablosu | 8000 Adresler 8000 addresses |
| Jumbo Frame Size | 10000, Byte |
| Supply voltage | 24 … 57 VDC |
| Enerji tüketimi maks. | 13 W |
| Power consumption (note) | 253 W with 8 PoE+; 30 W per port |
| ESD (contact/air discharge) | 8 KV / 15 KV |
| Baud rate | Bakır kablo: 10/1000 Mbit/s; Fiber optik:1000 Mbit/s Copper cable: 10/1000 Mbit/s; Fiber optic:1000 Mbit/s |
| Transmission medium (communication/fieldbus) | Fiber optik: SX Çoklu Mod, LX Tek Modlu Fiber optic: SX Multi-Mode, LX Single-Mode |
| LWL-Fasertyp | Tek modlu ve çok modlu Single-Mode und Multi-Mode |
| VLAN'lar | Port-based and tag-based (max. 5 VLANs) |
Bağlantı verisi
| Connection technology: communication/fieldbus | Bakır kablo: 8 x RJ-45; Fiber optik: 2 x SFP, LC fiber-optic connectors Copper cable: 8 x RJ-45; Fiber optic: 2 x SFP, LC fiber-optic connectors |
Geometrical Data
| Width | 50 mm / 1.969 inches 50 mm / 1.969 inch |
| Height | 160 mm / 6.299 inches 160 mm / 6.299 inch |
| Depth | 120 mm / 4.724 inches 120 mm / 4.724 inch |
Mekanik Veri
| Ağırlık | 560 g |
| Renk | açık gri |
| Uygunluk işareti | CE |
Environmental Requirements
| Surrounding air (operating) temperature | -10 … +60 °C -10 … 60 °C |
| Surrounding air (storage) temperature | -40 … +85 °C -40 … 85 °C |
| Koruma sınıfı | IP30 |
| Nısbi nem (yoğuşmasız) | 95 % |
| Montaj tipi | DIN-35 ray DIN 35 ray |
| Titreşime dayanıklı | IEC 60068-2-6 uyarınca acc. to IEC 60068-2-6 |
| Darbe direnci | IEC 60068-2-27 uyarınca acc. to IEC 60068-2-27 |
| EMC immunity to interference | EN 61000-6-2' göre acc. to EN 61000-6-2 |
| EMU: | EN 61000-6-4' göre acc. to EN 61000-6-4 |
Ticari Veri
| Pack. unit | 1 Adet 1 Stück |
| SAP'den ambalaj tipi | BOX |
| SAP tesis 01'den menşei | TW |
| GTIN | 4066966163421 4055144111088 |
| SAP tesis 01'den gümrük tarifesi no. | 85176200000 |
Environmental Product Compliance
| RoHS Compliance Status | Compliant,No Exemption |
